TP-Link TL-SG1005P-PD 5-Port Gigabit Desktop PoE+ Switch with 1-Port PoE++ In and 4-Port PoE+Out

Fotoğraf: TP-Link

TP-Link

TP-Link TL-SG1005P-PD 5-Port Gigabit Desktop PoE+ Switch with 1-Port PoE++ In and 4-Port PoE+Out

Model kodu: TL-SG1005P-PD · Modem ve Ağ

Cihaz Tipi
Switch
Port Sayısı
5
  • Ideal for Mains-Free Environments
  • Power over Ethernet, Flexible Network Deployment
  • Up to 250m Transmissions
  • PoE Auto Recovery
  • Plug and Play

TP-Link TL-SG1005P-PD 5-Port Gigabit Desktop PoE+ Switch with 1-Port PoE++ In and 4-Port PoE+Out · TP-Link Anlatıyor

Ports: 5× 10 Mbps/100 Mbps/1 Gbps RJ45 ports

1-Port Gigabit PoE++ In and 4-Port PoE+ Out: Supports up to 66 W / 47 W / 21 W/ 9 W PoE budget output when powered by 802.3bt Type 4, 802.3bt Type 3, 802.3at, and 802.3af PoE standard, respectively.*

Long-Range PoE+: With Extend Mode**, PoE transmission distance reaches up to 250 m, perfect for surveillance camera deployment in large areas.

PoE Auto Recovery: It guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices.

Metal Casing: Durable metal casing and desktop/wall-mounting design are well-suited for different environments.

Silent Operation: Industry-leading fanless design ensures silent operation, ideal for any home or business.

Plug and Play: No configuration and installation required.

Power Supply: The product only supports PoE power supply, not AC or DC power supply.

Learn more about TP-Link PoE technology >

Ideal for Mains-Free Environments

Powered by a PoE++ switch or PoE++ injector, no additional DC adapter is required.

Power over Ethernet, Flexible Network Deployment

Supports up to 66W/47W/21W/9W PoE budget output when powered by 802.3bt Type 4 (90 W), 802.3bt Type 3 (60 W), 802.3at, and 802.3af PoE, respectively.* The PoE-PD switch automatically detects the required PoE power for your devices and protects your non-PoE equipment from being damaged.

Up to 250m Transmissions

With extend mode, the PoE transmission distance reaches up to 250 m** —perfect for IP Camera deployment in large areas.

PoE Auto Recovery

Recovery mode helps automatically detect and reboot PD devices, such as cameras and APs, when they fall offline or go unresponsive—all without needing manual monitoring and restarts.

Extend Mode

Up to 250m Transmissions

With extend mode, the PoE transmission distance reaches up to 250m** —perfect for IP Camera deployment in large areas.

Recovery Mode

PoE Auto Recovery

Recovery mode helps automatically detect and reboot PD devices, such as cameras and APs, when they fall offline or go unresponsive—all without needing manual monitoring and restarts.

Plug and Play

1. Connect the Devices

IP Phone

IP Camera

Access Point

PoE++ Injector

Internet

Router

Ek sürüm bilgisi için lütfen destek sayfasına gidin.

*PoE budget calculations are based on laboratory testing. The actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors. **The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type. △ N umbers after different modes represent the effective ports for that mode.

Metin ve görseller üreticinin sitesinden birebir · TP-Link'daki ürün sayfası: https://www.tp-link.com/tr/business-networking/soho-switch-unmanaged/tl-sg1005p-pd/

Teknik Özellikler

2. Enjoy

Standartlar ve Protokoller
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x, IEEE 802.1p
Arabirim
• 5× 10/100/1000Mbps RJ45 Ports• 1× 10/100/1000 Mbps RJ45 PoE In Ports (compliance with 802.3af/at/bt Type3/bt Type4)• 4× 10/100/1000 Mbps RJ45 PoE Out Ports (compliance with 802.3af/at)• AUTO Negotiation• AUTO MDI/MDIX
Ağ Medyası
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)• EIA/TIA-568 100Ω STP (maximum 100m)• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)• EIA/TIA-568 100Ω STP (maximum 100m)• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)• EIA/TIA-568 100Ω STP (maximum 100m)
Fan Sayısı
Fanless
Güç Kaynağı
Only Powered by PoE Device
PoE Portları (RJ45)
• PoE In Port: Port 5, Compliance with 802.3af/at/bt Type3/bt Type4• PoE Out Ports: Ports 1-4, compliance with 802.3af/at• PoE Power Budget:-66 W when powered by 802.3bt Type 4 (90 W)-47 W when powered by 802.3bt Type 3 (60 W)-21 W when powered by 802.3at (30 W)-9 W when powered by 802.3af (15.4 W)
Boyutlar ( W X D X H )
6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm)
Maks. Güç Tüketimi
• 2.68 W (90W PoE In, with no PD connected)• 68.59 W (90W PoE In, with 66 W PD connected)
Max. Heat Dissipation
• 9.112 BTU/h (90W PoE In, with no PD connected)• 233.206 BTU/h (90W PoE In, with 66 W PD connected)
Anahtarlama Kapasitesi
10 Gbps
Paket Yönlendirme Hızı
7.44 Mpps
MAC Adres Tablosu
2k
Gelişmiş Özellikler
• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)• PoE Auto Recovery (Ports 1-4)• Mac Address Auto-Learning and Auto-Aging• IEEE 802.3x Flow Control• 802.1p/DSCP QoS• IGMP Snooping
İletim Metodu
Store-And-Forward
Sertifika
CE, FCC
Paket İçeriği
• TL-SG1005P-PD• Installation Guide
Ortam
• Operating Temperature: -30–70 ℃ (-22–158 ℉);• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing

Kaynak: TP-Link ürün sayfası; tablo üreticiye aittir, olduğu gibi aktarılmıştır.
